EP-Axle5 Passenger Car
The EP-Axle5 electric drive axle is based on the EP5 platform, with an output load of 3500 kg, a maximum torque of 5400 N.m, and a speed ratio of 15.58. It highly integrates the functional units such as the drive motor, reducer, and differential, and replaces the traditional mechanical transmission system with an integrated design, effectively reducing energy loss in the power transmission link and improving energy utilization efficiency. Its compact structure not only greatly saves chassis space and releases more space for battery pack layout, but also reduces the vehicle’s own weight through lightweight design, achieving “more hauling and faster running”.
As a subsidiary of EMAC, EVMac provides electric drive axles, drive motors, power batteries, and vehicle controllers. As the electrification of automobiles becomes an inevitable trend, EVmac has also entered the field of electric vehicle powertrain systems.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of EP-Axle5 Truck Electric Drive Axle
Integrate the motor and transmission system to reduce energy transmission loss and improve endurance.
Highly integrated design saves chassis space and facilitates vehicle layout and battery installation.
Simplify the mechanical structure, reduce the weight of the vehicle, and indirectly increase the payload.
Low maintenance: No complex mechanical transmission parts, reduce gear and bearing wear, and reduce maintenance costs.
Support torque vector distribution, optimize vehicle handling stability, and adapt to complex working conditions.
Technical Specifications
| PlatForm: | EP5 |
| Rated Load: | 3500 kg |
| Rim Installation Distance A: | 1571 mm |
| Spring distance B: | 952 mm |
| Maximum Torque: | 5400 N.m |
| Speed Ratio: | 15.58 |
| Motor Voltage: | 360 / 540 V |
| Motor Peak / Rated Power: | 90 / 35 – 115 / 60 kW |
| Motor Peak / Rated Torque: | 215 / 111.5 – 350 / 115 Nm |
| Motor Maximum / Rated Speed: | 12000 / 3000 – 11000 / 4244 RPM |
| Brake Specifications: | Air Brake: Ф 310 x 100 Oil Brake: Ф 310 x 90 |
| Wheel Bolts: | 6-M20 * 1.5 |
The truck electric drive system revolutionizes the traditional fuel-powered model, utilizing advanced electric motors and battery packs as the core power source. Through a sophisticated electronic control unit that adjusts the current in real-time, the electric motor can instantly deliver high torque, enabling rapid starts and efficient acceleration. The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience. CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components. CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs. RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF. RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons. CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios. Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.Truck Electric Drive Axle
Tourist Train
Traction System
Bogie and Braking System
Track Body Components
Maintenance Equipment
Railway Components
RailMac
Model | Rated Load | Maximum Torque | Speed Ratio | Motor Voltage |
| EP-Axle5 | 3500 kg | 5400 N.m | 15.58 | 360 / 540 V |
| EP-Axle6 | 3500 kg | 5700 N.m | 16.5 | 360 / 540 V |
| EP-Axle13 | 8500 kg | 13000 N.m | 19.89 | 380 V |
| EP-Axle19C | 13000 kg | 18000 N.m | 20.05 | 650 / 576 V |
| EP-Axle19C2 | 13000kg | 19256 | 25.338 | 540 V |
| ——END—— | ||||
coming soon……
coming soon……
coming soon……
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
