Rated Load : 13000 kg
Maximum Torque : 28000 N.m
Speed Ratio : 54.32 / 18.72
Motor Voltage : 540 V
EVMAC Product Model
As an outstanding enterprise in the industry, EVMAC has demonstrated strong strength and rich product lines in the field of core components for new energy vehicles. Its electric drive axles combine advanced mechanical design with sophisticated electronic control technology, and are characterized by high integration and high-efficiency transmission. They can provide vehicles with stable and strong power output, ensuring that the vehicle’s power response is timely and driving is smooth, whether in urban congested road conditions or high-speed driving scenarios, significantly improving the vehicle’s overall performance and driving experience. EVMAC has built a complete and efficient core component system for new energy vehicles with its electric drive axles, drive motors, power batteries, controllers and other high-quality products, and continues to play an important role in promoting the development of the new energy vehicle industry, contributing its own strength to the realization of the beautiful vision of green and smart travel.
Find Products by Applications
This is the list of all EVMAC for Electric Drive Axle、Drive Motor、Power Battery,Motor Controller applications.
Electric Driven Alxe
Rated Load : 3500 kg Rated Load : 3500 kg Rated Load : 13000 kg Rated Load : 13000 kg Rated Load : 8500 kg Rated Load : 3500 kg Rated Load : 3500 kg Rated Axle Load : 13 T Rated Axle Load : 13 T Rated Axle Load : 11.5 ~ 13 T Rated Axle Load : 11.5 T Rated Axle Load : 11.5 T Rated Axle Load : 8 T Rated Axle Load : 6 T Rated Axle Load : 6 T Rated Axle Load : 3.5 ~ 4.5 T Rated Axle Load : 3 T Rated Axle Load : 2 T
EP-Axle6 Truck
Maximum Torque : 5700 N.m
Speed Ratio : 16.5
Motor Voltage : 360 / 540 V
EP-Axle5 Truck
Maximum Torque : 5400 N.m
Speed Ratio : 15.58
Motor Voltage : 360 / 540 V
EP-Axle19C2 Passenger Car
Maximum Torque : 19256 N.m
Speed Ratio : 25.338
Motor Voltage : 540 V
EP-Axle19C Passenger Car
Maximum Torque : 18000 N.m
Speed Ratio : 20.05
Motor Voltage : 650 / 576 V
EP-Axle13 Passenger Car
Maximum Torque : 13000 N.m
Speed Ratio : 19.89
Motor Voltage : 380 V
EP-Axle6 Passenger Car
Maximum Torque : 5700 N.m
Speed Ratio : 16.5
Motor Voltage : 360 / 540 V
EP-Axle5 Passenger Car
Maximum Torque : 5400 N.m
Speed Ratio : 15.58
Motor Voltage : 360 / 540 V
QT130SPE
End Face Distance : 1860 mm
Leaf Spring Distance : 1054 mm
Total Speed Ratio : 56.7 / 23.5 / 46 / 19
QT130STPE
End Face Distance : 1860 mm
Leaf Spring Distance : 1040 mm
Total Speed Ratio : 56.6 / 32 / 16.7
QT115SPE
End Face Distance : 1860 mm
Leaf Spring Distance : 1040 mm
Total Speed Ratio : 75 / 38 / 20.8
QT115DTPE
End Face Distance : 1860 mm
Leaf Spring Distance : 1040 mm
Total Speed Ratio : 14.5
QT115TPE
End Face Distance : 1860 mm
Leaf Spring Distance : 1030 mm
Total Speed Ratio : 14.5
QT80SPE
End Face Distance : 1804 mm
Leaf Spring Distance : 1030 mm
Total Speed Ratio : 31.1 / 16.3
QT60SPE
End Face Distance : 1615 mm
Leaf Spring Distance : 940 mm
Total Speed Ratio : 28.202 / 11.379
QT60PE
End Face Distance : 1615 mm
Leaf Spring Distance : 940 mm
Total Speed Ratio : 16.5
QT30-45PE
End Face Distance : 1640 ~ 1495 mm
Leaf Spring Distance : 920 / 970 mm
Total Speed Ratio : 16.1
QT30PE
End Face Distance : 1470 mm
Leaf Spring Distance : 900 mm
Total Speed Ratio : 14.3
QT20PE
End Face Distance : 1535 mm
Leaf Spring Distance : 1080 mm
Total Speed Ratio : 14
Driven Motor
Volt : 540 VDC Volt : 320 VDC Volt : 618 VDC Volt : 350 VDC Volt : 540 VDC Volt : 540 VDC Volt : 320 VDC Volt : 540 VDC Volt : 350 VDC Volt : 640 VDC Volt : 540 VDC Volt : 360 VDC Volt : 540 VDC Volt : 540 VDC Volt : 540 VDC Volt : 540 VDC Volt : 600 VDC Volt : 600 VDC Volt : 540 VDC Volt : 540 VDC Volt : 500 VDC Volt : 540 VDC Volt : 540 VDC Volt : 5400 VDC Volt : 450 VDC Volt : 540 VDC Volt : 600 VDC Volt : 618 VDC Volt : 600 VDC Volt : 540 VDC The relevant products still under developing or waiting to be update, please contact our sales team for latest updates.
TZ180XS017A
Rated / Prak Power : 20 / 40 kw
Rated / Peak Torque : 150 / 300 Nm
Rated / Peak RPM : 1273 / 2400 RPM
TZ180XS009-II
Rated / Prak Power : 30 / 60 kw
Rated / Peak Torque : 100 / 225 Nm
Rated / Peak RPM : 2865 / 9000 RPM
TZ180XS009-I
Rated / Prak Power : 60 / 125 kw
Rated / Peak Torque : 120 / 200 Nm
Rated / Peak RPM : 4775 / 7500 RPM
TZ180XS014E
Rated / Prak Power : 40 / 75 kw
Rated / Peak Torque : 48 / 130 Nm
Rated / Peak RPM : 8100 / 12000 RPM
TZ220XS017A
Rated / Prak Power : 60 / 80 kw
Rated / Peak Torque : 360 / 560 Nm
Rated / Peak RPM : 1600 / 2400 RPM
TZ220XS020A
Rated / Prak Power : 32.5 / 70 kw
Rated / Peak Torque : 225 / 450 Nm
Rated / Peak RPM : 2860 / 6500 RPM
TZ220XS028A
Rated / Prak Power : 30 / 60 kw
Rated / Peak Torque : 100 / 225 Nm
Rated / Peak RPM : 8100 / 12000 RPM
TZ220XS026A
Rated / Prak Power : 70 / 145 kw
Rated / Peak Torque : 150 / 330 Nm
Rated / Peak RPM : 4450 / 12000 RPM
TZ220XS013A
Rated / Prak Power : 60 / 130 kw
Rated / Peak Torque : 140 / 32 Nm
Rated / Peak RPM : 4000 / 12000 RPM
TZ260XS002A
Rated / Prak Power : 90 / 165 kw
Rated / Peak Torque : 300 / 600 Nm
Rated / Peak RPM : 2860 / 10000 RPM
TZ290XS027A
Rated / Prak Power : 110 / 190 kw
Rated / Peak Torque : 450 / 900 Nm
Rated / Peak RPM : 2400 / 7500 RPM
TZ290XS022B
Rated / Prak Power : 70 / 120 kw
Rated / Peak Torque : 445 / 1100 Nm
Rated / Peak RPM : 1500 / 4500 RPM TZ290XS024B
Rated / Prak Power : 70 / 120 kw
Rated / Peak Torque : 445 / 1100 Nm
Rated / Peak RPM : 1500 / 4500 RPM
TZ290XS010
Rated / Prak Power : 80 / 150 kw
Rated / Peak Torque : 230 / 650 Nm
Rated / Peak RPM : 3320 / 10000 RPM TZ290XS036A
Rated / Prak Power : 70 / 150 kw
Rated / Peak Torque : 225 / 450 Nm
Rated / Peak RPM : 2971 / 10000 RPM TZ290XS017C
Rated / Prak Power : 77.5 / 150 kw
Rated / Peak Torque : 238 / 554 Nm
Rated / Peak RPM : 3118 / 7500 RPM
TZ380XS017J
Rated / Prak Power : 250 / 410 kw
Rated / Peak Torque : 1750 / 2800 Nm
Rated / Peak RPM : 1364 / 3500 RPM
TZ380XS017G
Rated / Prak Power : 250 / 360 kw
Rated / Peak Torque : 1405 / 2500 Nm
Rated / Peak RPM : 1700 / 3500 RPM
TZ380XS016H
Rated / Prak Power : 120 / 240 kw
Rated / Peak Torque : 1200 / 2500 Nm
Rated / Peak RPM : 955 / 3500 RPM
TZ380XS016L
Rated / Prak Power : 120 / 240 kw
Rated / Peak Torque : 1200 / 2800 Nm
Rated / Peak RPM : 955 / 3000 RPM TZ380XS029C
Rated / Prak Power : 150 / 240 kw
Rated / Peak Torque : 850 / 1400 Nm
Rated / Peak RPM : 1685 / 5000 RPM
TZ380XS029B
Rated / Prak Power : 160 / 270 kw
Rated / Peak Torque : 750 / 1310 Nm
Rated / Peak RPM : 2038 / 5000 RPM TZ380XS024B-II
Rated / Prak Power : 90 / 180 kw
Rated / Peak Torque : 900 / 2100 Nm
Rated / Peak RPM : 955 / 3500 RPM TZ380XS024B-I
Rated / Prak Power : 85 / 170 kw
Rated / Peak Torque : 850 / 1800 Nm
Rated / Peak RPM : 955 / 3500 RPM TZ380XS027C
Rated / Prak Power : 115 / 180 kw
Rated / Peak Torque : 550 / 1200 Nm
Rated / Peak RPM : 2000 / 4000 RPM TZ380XS027B
Rated / Prak Power : 100 / 150 kw
Rated / Peak Torque : 500 / 1000 Nm
Rated / Peak RPM : 1910 / 3500 RPM
TZ400XS015B
Rated / Prak Power : 250 / 360 kw
Rated / Peak Torque : 1600 / 2500 Nm
Rated / Peak RPM : 1500 / 3500 RPM
TZ400XS009A
Rated / Prak Power : 200 / 260 kw
Rated / Peak Torque : 1140 / 3000 Nm
Rated / Peak RPM : 1675 / 3300 RPM
TZ400XS013A
Rated / Prak Power : 250 / 410 kw
Rated / Peak Torque : 1750 / 2800 Nm
Rated / Peak RPM : 1364 / 3500 RPM TZ400XS010A
Rated / Prak Power : 100 / 200 kw
Rated / Peak Torque : 1061 / 2500 Nm
Rated / Peak RPM : 900 / 2400 RPMProducts Not Available
Power Battery
Standard Voltage : 3.66 V Standard Voltage : 3.66 V Standard Voltage : 3.66 V Standard Voltage : 3.74 V Standard Voltage : 3.22 V Standard Voltage : 3.22 V Standard Voltage : 3.22 V Standard Voltage : 3.22 V Standard Voltage : 3.21 V Standard Voltage : 3.20 V Standard Voltage : 3.20 V Standard Voltage : 3.22 V Standard Voltage : 3.22 V
M43 Battery
Standard Capacity : 5.45 Ah
Weight : 189 ± 5 g
Dimensions : 12.6 * 120.2 * 69.2 mm
M42 Battery
Standard Capacity : 15 Ah
Weight : 426 ± 7 g
Dimensions : 17.7 * 148.7 * 78.8 mm
M41 Battery
Standard Capacity : 19.5 Ah
Weight : 547 ± 15 g
Dimensions : 17.7 * 148.7 * 98.8 mm
M12 Battery
Standard Capacity : 188 Ah
Weight : 2896 ± 50 g
Dimensions : 50.6 * 301.3 * 88.6 mm
LF125H Battery
Standard Capacity : 125 Ah
Weight : 2310 ± 69 g
Dimensions : 47.7 * 200.7 * 115 mm
L11 Battery
Standard Capacity : 154 Ah
Weight : 2755 ± 10 g
Dimensions : 33.7 * 346.4 * 110 mm
A41 Battery
Standard Capacity : 106 Ah
Weight : 1880 ± 30 g
Dimensions : 52.2 * 148.6 * 118.5 mm
A27-V2.1 Battery
Standard Capacity : 124.9 Ah
Weight : 2240 ± 30 g
Dimensions : 37.2 * 309.5 * 88 mm
A27-V1 Battery
Standard Capacity : 127.2 Ah
Weight : 2220 ± 30 g
Dimensions : 37.2 * 309.5 * 88 mm
A25 Battery
Standard Capacity : 132.2 Ah
Weight : 2281 ± 35 g
Dimensions : 30.5 * 314 * 17 mm
A24 Battery
Standard Capacity : 172 Ah
Weight : 3160 ± 40 g
Dimensions : 36.7 * 301 * 132.5 mm
A22 Battery
Standard Capacity : 178.1 Ah
Weight : 3170 ± 30 g
Dimensions : 61 * 281.1 * 88. mm
A21 Battery
Standard Capacity : 154 Ah
Weight : 2755 ± 30 g
Dimensions : 33.7 * 346.4 * 110 mm
Motor Controller
Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 250 ~ 420 V Rated Input Voltage : 250 ~ 420 V Rated Input Voltage : 250 ~ 420 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 400 ~ 750 V Rated Input Voltage : 250 ~ 420 V Input Voltage Range : DC 250 ~ 750 V Rated Power :132 kw Input Voltage Range : 330 ~ 440VAC Rectifier Rated Power :160 kw Rectifier Rated Output Current : 380 A Input Voltage Range: DC 450 V ~ 750 V
SA500 Controller
Rated Current : 480 A
Peak Output Voltage : 380 Vac
Peak Current : 850 A
SA360 Controller
Rated Current : 400 A
Peak Output Voltage : 380 Vac
Peak Current : 620 / 700 A
SA220 Controller
Rated Current : 300 A
Peak Output Voltage : 380 Vac
Peak Current : 570 A
SA150C Controller
Rated Current : 176 A
Peak Output Voltage : 380 Vac
Peak Current : 350 A
SA150B Controller
Rated Current : 230 A
Peak Output Voltage : 380 Vac
Peak Current : 420 A
SA150A Controller
Rated Current : 230 A
Peak Output Voltage : 237 Vac
Peak Current : 460 A
SA50B Controller
Rated Current : 140 A
Peak Output Voltage : 237 Vac
Peak Current : 330 A
SA50A Controller
Rated Current : 120 A
Peak Output Voltage : 237 Vac
Peak Current : 270 A
DA500 Controller
Rated Current : 305 A
Peak Output Voltage : 380 Vac
Peak Current : 530 A
DA360D Controller
Rated Current : 230 / 305 A
Peak Output Voltage : 380 Vac
Peak Current : 420 / 530 A
DA360C Controller
Rated Current : 230 A
Peak Output Voltage : 380 Vac
Peak Current : 420 A
DA360B Controller
Rated Current : 160 / 305 A
Peak Output Voltage : 380 Vac
Peak Current : 300 / 530 A
DA360A Controller
Rated Current : 160 / 230 A
Peak Output Voltage : 380 Vac
Peak Current : 300 / 420 A
DA220 Controller
Rated Current : 176 A
Peak Output Voltage : 380 Vac
Peak Current : 350 A
DC180B Controller
Rated Current : 108 A
Peak Output Voltage : 380 Vac
Peak Current : 175 A
DC180A Controller
Rated Current : 120 ~ 200 A
Peak Output Voltage : 237 Vac
Peak Current : 270 ~ 400 A
M04 Auxiliary Drive Multi-in-One-I
Output Voltage : 27.5 VDC
Power Rating : 3 / 5 kw @ 24 V
Rated Current : 110 / 180 A
M15 Main Drive Multi-in-One-I
Peak Power :198 kw
Rated AC Output Current : 205 A
Control Box Protection Level : IP67
Car Inverter Water Cooling V1
Inverter Rated Power : 132 kw
Double Main Drive Six-In-One-I
Output Volts: 27.5 VDC
Power Rating: 3 / 5 kw @ 24 V
Rated Current: 110 / 180 A
