M42 Battery
The M42 is a modern power battery represented by lithium-ion batteries, with a nominal voltage of 3.66 V and a capacity of 15 Ah. The energy density is 128 Wh / kg. The efficient conversion of electrical energy and chemical energy is achieved through the redox reaction of positive and negative electrode materials. Its modular design allows flexible combination according to different application scenarios, from the energy supply of electric vehicles with a range of 100 kilometers to the megawatt-level power regulation of energy storage power stations, all of which can operate stably with excellent charging and discharging efficiency and safety performance. The built-in battery management system (BMS) is like an intelligent housekeeper, monitoring voltage, temperature and charging and discharging status in real time, extending battery life through balancing technology, and cooperating with the thermal management system to ensure performance in extreme environments.
As a subsidiary of EMAC, EVMac provides electric drive axles, drive motors, power batteries, and vehicle controllers. As the electrification of automobiles becomes an inevitable trend, EVmac has also entered the field of electric vehicle powertrain systems.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of M42 Power Battery
Integrate the motor and transmission system to reduce energy transmission loss and improve endurance.
Highly integrated design saves chassis space and facilitates vehicle layout and battery installation.
Simplify the mechanical structure, reduce the weight of the vehicle, and indirectly increase the payload.
Low maintenance: No complex mechanical transmission parts, reduce gear and bearing wear, and reduce maintenance costs.
Support torque vector distribution, optimize vehicle handling stability, and adapt to complex working conditions.
Technical Specifications
| Nominal Voltage: | 3.66 V |
| Nominal Capacity: | 15 Ah |
| Standard Cycle: | 2000 |
| Maximum Discharge Rate: | 20 C |
| Weight: | 426 ± 7 |
| Energy Density: | 128 |
| Dimensions: | 17.7 mm * 148.7 mm * 78.8 mm |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T , L/C |
Power batteries serve as the energy cornerstone in the new energy field. As the core units for energy storage and supply, they enable the efficient storage and release of electrical energy through reversible electrochemical reactions. Take the mainstream lithium – ion batteries as an example. The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience. CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components. CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs. RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF. RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons. CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios. Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.Power Battery
Tourist Train
Traction System
Bogie and Braking System
Track Body Components
Maintenance Equipment
Railway Components
RailMac
Model | Nominal Voltage | Nominal Capacity | Weight | Energy Density |
| A21 | 3.22 V | 154 Ah | 2755±30 | 180 kg |
| A22 | 3.22 V | 178.1 Ah | 3170±30 | 180 kg |
| A24 | 3.2 V | 172 Ah | 3160±40 | 174 kg |
| A25 | 3.2 V | 132.2 Ah | 2281±35 | 185 kg |
| A27-V1 | 3.21 V | 127.2 Ah | 2220±30 | 180 kg |
| A27-V2.1 | 3.22 V | 124.9 Ah | 2240±30 | 180 kg |
| A41 | 3.22 V | 106 Ah | 1880±30 | 182 kg |
| L11 | 3.22 V | 22 Ah | 628±10 | 112 kg |
| LF125H | 3.22 V | 125 Ah | 2310±69 | 174 kg |
| M12 | 3.74 V | 188 Ah | 2896±50 | 242 kg |
| M41 | 3.66 V | 19.5 Ah | 547±15 | 130 kg |
| M42 | 3.66 V | 15 Ah | 426±7 | 128 kg |
| M43 | 3.66 V | 5.45 Ah | 189±5 | 105 kg |
| ——END—— | ||||
coming soon……
coming soon……
coming soon……
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
