Truck Electric Drive Axle

The truck electric drive system revolutionizes the traditional fuel-powered model, utilizing advanced electric motors and battery packs as the core power source. Through a sophisticated electronic control unit that adjusts the current in real-time, the electric motor can instantly deliver high torque, enabling rapid starts and efficient acceleration. Compared to diesel engines, the electric drive system significantly reduces carbon emissions and minimizes noise pollution with its near-silent operation, greatly enhancing the driving and riding environment. Meanwhile, the application of regenerative braking technology allows the vehicle to convert kinetic energy into electrical energy during braking, effectively extending the driving range. Additionally, the modular design facilitates maintenance and upgrades, bringing a cleaner, smarter, and more cost-effective solution to the logistics and transportation industry.
If you are in need of machine model that not available on our website for the moment, please contact EVMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at EVMAC.

[modula id=”987525368″]

Oops! It seems that the entered tour doesn't exist. Please enter correct shortcode.

General Specifications of Truck Electric Drive Axle

Rated Load:3500 – 13000 kg
Rim Installation Distance A:1571 – 1832 mm
Spring distance B:
952 – 1030 mm
Maximum Torque:
5400 –  28000 N.m
Speed ​​Ratio:
15.58 – 54.32
Motor Voltage:350 / 540 V
Motor Peak / Rated Power:115  / 60  – 160 / 90 kW
Motor Peak / Rated Torque:350  / 135 – 500 / 200 Nm
Motor Maximum / Rated Speed:11000 / 4244  – 9000 / 4300 RPM
Brake Specifications:

Air Brake: Ф 310 x 100 – 410 x 180

Oil Brake: Ф 310 x 90 – 310 x 100

Truck Electric Drive Axle

The truck electric drive system revolutionizes the traditional fuel-powered model, utilizing advanced electric motors and battery packs as the core power source. Through a sophisticated electronic control unit that adjusts the current in real-time, the electric motor can instantly deliver high torque, enabling rapid starts and efficient acceleration.

FIND MORE

Tourist Train

The CRRC Zhuzhou 1435 series dual rail sightseeing car inherits the technological DNA of CRRC high-speed rail and is designed for in-depth sightseeing in scenic areas. The innovative double-decker structure features a panoramic window on the first floor for comfortable all-weather sightseeing and an open-top layout on the second floor for a 360° immersive natural experience.

FIND MORE

Traction System

CHSR's CHSR™ CC750 air-cooled converter is a highly integrated traction and auxiliary "two-in-one" core equipment. It condenses key power conversion functions into a single compact enclosure, providing robust and stable power for intercity trains through standardized modular design, intelligent air cooling (IP65 protection), and mature and reliable components.

FIND MORE

Bogie and Braking System

CRRC Braking Systems Co., Ltd.'s disc brake calipers use hydraulic or pneumatic-hydraulic conversion drive technology.They integrate automatic gap adjustment, modular caliper body, and three-point floating suspension design to ensure precise contact between brake pads and discs.

FIND MORE

Track Body Components

RailMac provides railway solutions, focusing on one-stop Lince/Huanji wiper services (R&D, production, maintenance) plus rail air conditioning. It offers diverse wipers (DC110V/74V/24V, pneumatic) and developed China’s first IP-owned CRH3 EMU wiper, with products batch-loaded in CRH380/CR400BF/CR300BF.

FIND MORE

Maintenance Equipment

RunWell is a high-tech enterprise specializing in the fields of rail transit and military industry. Its car lift machine products integrate German drive technology (such as the Demag three-in-one modular system) with intelligent control, supporting heavy-duty conditions of over 150 tons.

FIND MORE

Railway Components

CRRC specializes in innovative environmental protection sanitation systems. Products like vacuum water - saving toilet modules and waterless ecological toilets, made in an orderly factory, are applied in railways, public facilities, and outdoor scenarios.

FIND MORE

RailMac

Partnering with global leaders, RailMac offers superior railway equipment and solutions at competitive prices. It hit milestones like Thailand’s 2017 first local train, pioneered SEA new energy trains, and joined Russia’s high-speed rail project, boosting its railway industry presence.

FIND MORE

Truck Electric Drive Axle Catalogue

Model

Rated Load

Bridge Shell Type

Model

Rated Load

Bridge Shell Type

EP-Axle53500 kgExpansion TypeEP-Axle63500 kgCasting
EP-Axle28D13000 kgExpansion Type
——END——

Truck Electric Drive Axle

This is the list of all series of Truck Electric Drive Axle.
Click here to find Truck Electric Drive Axle by type.

EP-Axle28D Truck

EP-Axle28D Truck

Rated Load : 13000 kg
Maximum Torque : 28000 N.m
Speed ​​Ratio : 54.32 / 18.72
Motor Voltage : 540 V

EP-Axle6 Truck

EP-Axle6 Truck

Rated Load : 3500 kg
Maximum Torque : 5700 N.m
Speed ​​Ratio : 16.5
Motor Voltage : 360 / 540 V

EP-Axle5 Truck

EP-Axle5 Truck

Rated Load : 3500 kg
Maximum Torque : 5400 N.m
Speed ​​Ratio : 15.58
Motor Voltage : 360 / 540 V
